Jigsaw Blades
No matter what material you are intending to separate, what the profile looks like or whether or not you have to "follow the curve" with your saw – our jigsaw blades meet all of your requirements.
Jigsaw Blades
GUHEMA CV-flex
- Conically ground blade body, teeth ground sharp
- Curve cutting blade with double-sided, clean cutting edge path
- Suitable for soft wood, plywood, fibreboard and coated plates
- Similar to Bosch: T 101 A0
Order No.: | Tooth separation | Sawblade length | Wood cutting area |
---|---|---|---|
JBV077K14KS | 1.4 TPI | 77 mm | 1,5 - 20 mm |
GUHEMA Bi-lastic
- Tooth-set and milled teeth
- Made of bi-metal
- Sandwich-Material Professional
- For straight cuts in steel, stainless steel and non-ferrous metal
- Ideally suitable to cut profiles and tubes up to 80 mm
- Similar to Bosch: T 318 AF
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JBF132N10GN | 1.0 TPI | 132 mm | 1,2 - 2,5 mm |
GUHEMA Bi-lastic
- Tooth-set and milled teeth
- Made of bi-metal
- Ideally suitable to cut profiles and tubes up to 80 mm
- For straight cuts in steel, stainless steel and non-ferrous metal
- Similar to Bosch: T 318 BF
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JBF132N18GN | 1.8 TPI | 132 mm | 2,3 - 6 mm |
Car Body Jigsaw Blades
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JSF0950Q | 32.0 TPI | 95 mm | < 1 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JSF0950P | 24.0 TPI | 95 mm | > 1 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JSF0950N | 18.0 TPI | 95 mm | 1,5 - 3 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JSF0950L | 14.0 TPI | 95 mm | 2 - 4 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JLF0950Q | 32.0 TPI | 95 mm | < 1 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JLF0950P | 24.0 TPI | 95 mm | > 1 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JLF0950N | 18.0 TPI | 95 mm | 1,5 -3 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JLF0950L | 14.0 TPI | 95 mm | 2 - 4 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JOF0950Q | 32.0 TPI | 95 mm | < 1 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JOF0950P | 24.0 TPI | 95 mm | > 1 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JOF0950N | 18.0 TPI | 95 mm | 1,5 - 3 mm |
GUHEMA Bi-lastic
- Sharply milled toothing
- Hardened to the point as part of a high-vacuum hardening process for maximum service life
- The sawblade without compromise, made of bi-metal, achieves high performance with materials that are difficult to machine and with a tensile strength of up to 1100 N/mm2
Order No.: | Tooth separation | Sawblade length | Metal cutting area |
---|---|---|---|
JOF0950L | 14.0 TPI | 95 mm | 2 - 4 mm |
